1-42KW Inline Chemical Heaters

Name: 142KW Inline Chemical Heaters
Brand: Precise Heater
Price: 1 USD

Best 1-42KW Inline Chemical Heaters wholesale

Brand Name : Precise Heater

Model Number : PU202

Certification : CSA,UL,CE

Place of Origin : China

MOQ : 1 unit

Price : US$1,000 - 9,000 / unit

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30 units per month

Delivery Time : 15-25 days

Packaging Details : Export Wooden Case

Material : PFA/PTFE/PVDF

Color : White

Safety Features : Liquid level sensor,Ground wire options

Applications : Semiconductor Wet Processes,Solar/Photovoltaic Wafer Cleaning

SPECIFICATIONS : 3,000 watts up to 18,000 watts

Voltages : 200 to 600 volts, single or three phase

Contact Now

In-line PFA Fluid Heaters - Inline Chemical Heaters PFA/PTFE/PVDF

Specialty In-Line PFA Fluid Heaters

Higher Power, More Customizable, & Compact

Overview

HC Series in-line heaters are ideal for high-temperature, ultrapure processes. They feature PFA flow paths for optimal compatibility with aggressive chemicals. Their special internal fittings eliminate O-rings seals for enhanced cleanliness. They utilize the low-mass PreciseHeater® heating element with low watt density to provide

Features & Benefits

Ultrapure PFA wetted surfaces compatible with aggressive chemicals
Flexible designs allow customized safety features, voltages, and power outputs
Fast temperature response with low watt density
Up to 95°C at 60 psi
1-42 kW models available
Increased power in small footprint

Safety Features

Junction box protects heater and sensor wires from harsh environments
Over-temperature thermocouple regulates temperature by limiting heat within housing
Thermal cut-off ensures temperature does not exceed range to prevent overheating
Process thermocouple ensures fluid temperature is accurately maintained
Platinum-tipped ground wires protect user and heater

Ultrapure Fluid Heating Element

HC Series PFA in-line fluid heaters feature the PreciseHeater®heating coil. This heating element offers excellent power output in a compact package. It has a low watt density, which extends the heater life by spreading out the wattage. The heating element is coated in PFA materials, which eliminates the need for nitrogen purge, and reduces operating costs.

Model	Wetted Material	Housing Material	MaxTemp*	Pressure	Power	Voltage
HC	PFA	Pipe	120°C	60 psi at 120°C	1-10 kW	120-480 VAC, 1 and 3-phase
LHT	PFA	Pipe	95°C	60 psi at 95°C	1-42 kW	208-480 VAC, 1 and 3-phase

Legacy In-Line PFA Fluid Heater Models

Since 1992, PreciseHeater has been an industry leader in ultrapure heating, paving the way for PVDF, PTFE, and PFA in-line fluid heaters. With new technology and almost half a decade later, PreciseHeater has improved on legacy designs with the HC Series of PFA in-line heater that offer higher temperatures, enhanced cleanliness, extended life spans, improved reliability, and more. PreciseHeater continues to support legacy heaters. Contact us for details.

Legacy Models	Material	Max Temp*	kW
LHM	PFA Chemlock®	120°C	1-6kW
LHN	PFA Chemlock®	120°C	7-12kW
LHX	PTFE Molded	100°C	1-7kW
LHY	PTFE Molded	100°C	10-12kW
